| Height | 68mm |
|---|---|
| Length | 94mm |
| Width | 18mm |
| Degree of protection | IP20 |
|---|
| Carton | 100 |
|---|---|
| Limited discharge current (8/20us) | Imax: 60kA |
| Operating permanent voltage | 275V AC |
| Operating temperature | -40°C / +70°C |
| Surge current (10/350µs) | Imp: 12,5kA |
| Voltage protection level | Up: <2,0kV |
| Type | T1+T2 |
| Brand | Schelinger |
